PLANET VoIP Телефоны серии VIP-103PT/153PT/153T/153M. Инструкция по эксплуатации
31
Часть 4
Примеры настройки
В этих примерах показана пошаговая настройка для разных типов подключения.
Peer to peer (P2P) mode
VIP-103PT to VIP-103PT connection via IP address
Assuming there are two VIP-103PT in the network the IP address are 192.168.0.1, 192.168.0.2
192.168.0.2
192.168.0.1
In peer-to-peer (P2P) mode, you can direct pickup the handset and dial the IP address of the remote VIP-103PT using the keypad as below:
Then the phone of 192.168.0.2 should ring. You can do the same thing to the second VIP-103PT.
1
9
2
*
1
8
*
0
*
2
#
6
IP PBX extension configurations – IPX-1000/IPX-1500
Machine configurations on VIP-103PT
a)
Log in machine via web browser, and browse to the H.323 configuration page, and enable the “IPX ” feature.
b)
After enabling the “IP extension” feature, please enable hotline feature, and insert the IP address of IP PBX system. PLANET IPX-1000,
IPX-1500).
After these configurations, be sure to click the “DONE” button to apply settings and browse to “System Configuration” menu to reboot
the machine to make the settings effective.
Внимание!: if the VIP-103PT setting DHCP client to connect the IPX-1500 DHCP server, in the hot list setting, please set up auto
mode to connect the IPX-1500.
