PLANET VoIP Телефоны серии VIP-103PT/153PT/153T/153M. Инструкция по эксплуатации
34
VIP-153PT to VIP-153T connection via IP address
Assume there are two SIP IP phone in the network the IP address are 192.168.0.1, 192.168.0.2
192.168.0.1
192.168.0.2
In peer-to-peer (P2P) mode, you can direct pickup the handset and dial the number using the keypad as below:
1
9
2
*
1
6
8
*
0
*
2
#
Then the phone of 192.168.0.2 should ring. You can do the same thing to the second VIP-153T.
y
If the IP address of the remote calling party is known, you may
directly make calls via its IP address and end with an “#”.
y
If the IP phones are installed behind a NAT/firewall/ IP sharing
device, please make sure the NAT device support SIP applications
before making calls
L
Hint
VIP-153PT to VIP-153T connection via SIP telephone number
Number: 200
Number: 100
VIP-153PT
WAN IP Address
(192.168.0.1)
VIP-153T
WAN IP Address
(192.168.0.2)
ШАГ 1:
Please browse machine “SIP configuration” menu, and enable the Proxy mode. Insert IP address
of the remote calling party in the “Proxy Server Address” field. Sample configuration screen is
shown below:
