ENGLISH
72
More about this unit
General
Turning on the power
• By pressing SOURCE on the monitor panel, you
can also turn on the power. If the source is ready,
playback starts.
FM/AM
Storing stations in memory
• When SSM is over, received stations are preset in No.
1 (lowest frequency) to No. 6 (highest frequency).
Disc
General
• In this manual, words “track” and “file” are
interchangeably used.
• This unit can also play back 8 cm discs.
• This unit can only play back audio CD (CD-DA) files if
different type of audio files (MP3/WMA/WAV/AAC)
are recorded in the same disc.
• This unit can display only one-byte characters. No
other characters can be correctly displayed.
Inserting a disc
• When a disc is inserted upside down or has no
playable files, “Cannot play this disc Check the disc”
appears on the monitor. Eject the disc.
Ejecting a disc
• If “No disc“ appears after removing a disc, reattach a
disc or select another playback source.
• If the ejected disc is not removed within 15 seconds,
the disc is automatically inserted again into the
loading slot to protect it from dust.
Speaker/signal indicators for DVD
• The speaker indicators—square around the letters
lights in light blue when the corresponding speakers
are set to <Large> or <Small>.
• The center speaker indicator—square around “C”
lights in light blue, when the center speaker is set
to <Large> or <Small> and when surround is
activated.
• Sounds come out of the speakers whose speaker
indicators are lit.
• The SW indicator lights up when <SW (Subwoofer)>
is set to <On>.
• The signal indicators indicate the incoming
signals—L (front left) / R (front right) / C (center)
/ LFE (low frequency effect) / LS (left surround) / RS
(right surround) / S (monaural surround).
• If the speaker is activated, but the signals
corresponding to the speaker are not coming in, the
signal indicators changes their color from white to
black to indicate no signals coming in.
Changing the source
• If you change the source with Dual Zone deactivated,
playback also stops without ejecting the disc.
Next time you select “DISC” for the playback source,
disc play starts from where it has been stopped
previously.
Signal indicators
Speaker indicators
