64
ENGLISH
Menu items
Selectable settings, [reference page]
Disc
Speaker Size
*
5
You can adjust the speaker size setting.
As you change the speaker size, the speaker on the screen changes its
size. When <None> or <Off> is selected, the speaker is shaded.
• L/R (Front): Small, Large
• C (Center): None, Small, Large
• LS/RS (Surround): None, Small, Large
• SW (Subwoofer): On, Off
• Speaker size: <Large> for 13-cm diameter or more; <Small> for
13 cm or less.
• If you select <Large> or <Small> for non-connected speakers, the
incoming signals for the non-connected speakers will not come out
of any other speakers.
• Front speakers and surround speakers cannot be adjusted separately
for left and right speakers.
Regardless of the setting above...
• No sound comes out of the subwoofer while playing Dolby Pro Logic
II Movie or Music if the front speaker is set to <Large>.
• No sound comes out of the center speaker when surround is
deactivated.
Speaker Level
*
6
You can adjust the output level of the activated speakers (
☞
<Speaker Size> above), monitoring the test tone.
L/C/R/RS/SW
*
7
/LS: adjust the output level of each speaker in the
range of –10dB to +10dB; Initial 00dB.
• Press [Test] to turn on and off the test tone.
Speaker Distance
*
6, 8
You can adjust the speaker output timing.
L/C/R/RS/LS: adjust the speaker distance from the listening position in
the range of 15cm/6 inches to 600 cm/240 inches in 15-cm/6-
inch step; Initial 120 cm/48 inches (for center speaker), 150
cm/60 inches (for other speakers).
• Press [cm
Ôinch] to change the measuring unit—cm and inch.
*
5
Selectable only for “DISC,” “SD,” and “USB.” (Playback stops when you change the setting.)
*
6
Selectable only for “DISC,” “SD,” and “USB.”
*
7
This subwoofer level setting takes effect only when surround is activated. (
☞ also page 27)
*
8
This setting does not take effect for MPEG1/MPEG2 and DivX with MP3 audio track.
