66
ENGLISH
Menu items Selectable settings, [reference page]
Input
External Input * 13 For connecting an external component to the CD changer jack on the
rear.
Changer/iPod/D. player
* 14 : CD changer, iPod, or D. player
☞ [47, 53]
External: Any other than the above.
☞ [57]
• For connecting the Bluetooth adapter and DAB tuner, this setting is
not required. It is automatically detected.
Others
Beep Off: Cancels.
On: Activates the key-touch tone.
Telephone Muting * 15 Off: Cancels.
Muting1, Muting2: Select either one which mutes the sounds while
using the cellular phone.
Power LED Flash Off: Cancels.
On: When the ignition is turned off, the lamp on the
button
flashes.
TouchPanel Sens. Change the sensitivity of the touch panel. As the number decreases,
sensitivity become higher. 1/2/3; Initial 2
Initialize Initialize all settings you have made in <AV Menu>. Press and hold
[Enter] to initialize the settings, then reset the unit (
☞ page 3).
* 13 Not selectable when the component connected to the CD changer jack is selected as the source.
* 14 The name of the component detected through the CD changer jack is shown.
* 15 The TEL MUTING lead connection is required. See Installation/Connection Manual (separate volume).
Disc Surround * 16
Menu items Selectable settings, [reference page]
Surround On, Off,
☞ [27]
Surround Mode Auto, Through, Dolby PL II Movie, Dolby PLII Music,
☞ [27]
Panorama On, Off,
☞ [27]
Center Width * 17 00 to 07; Initial 04,
☞ [28]
* 16 Selectable only for “DISC”, “SD,” and “USB.”
* 17 This setting takes effect only when the center speaker is activated.
