OPERATIONS
27
ENGLISH
Enjoying surround sounds
You can enjoy multi-channel surround playback
through the front, center, surround speakers.
• After connecting the center speaker, make
sure to activate the center speaker; otherwise,
no sound comes out of the center speaker (
☞
page 64).
• Surround mode can also be used for “USB” and “SD.”
MULTI: For multi-channel encoded sources such as
Dolby Digital * 1 , DTS * 2 , and DVD Audio. (When
activated, “MULTI” is shown on the source
information screen.)
Dolby Pro Logic II (Movie/Music): For 2 channel
sources except for DivX/MPEG1/MPEG2 discs.
To turn on the surround...
1
2
3
• Off: Deactivates surround.
• On: Activates surround
= go to the following
steps.
4
• Auto: When multi-channel digital signals come
in, “MULTI” surround is activated.
When 2-channel or 2.1-channel signals come in,
“4CH STEREO” is activated.
• Through: All incoming channel signals are sent
to the corresponding speakers.
• Dolby PL II Movie: Activates Dolby Pro Logic II
Movie.
• Dolby PL II Music: Activates Dolby Pro Logic
II Music. You can adjust <Panorama> and
<Center Width> setting (
☞below).
Only when selecting <Dolby PL II Music>
After step 4 above...
1
Activate <Panorama>.
• Panorama: Select <On> to add wraparound
sound effect.
Continued on the next page
