Part 9: Gas conversion
Your cooker can operate both
Natural Gas and LPG. You can
convert by changing the gas
source and the top burner, oven
and g r i l l I n j e c t o r s . T h e
replacement procedure of the
injectors are explained below.
Call authorized Service for gas
convertion.
Replacement of the
top burner injector
Take off the burner head and
burner cap before starting this
procedure. Then:
1. Remove the injector inside
the top burner with a suitable
bit. Later, install the new
injector by covering the injector
threads with leakage
preventing
material. Flame failure
device
spark plug
Reduced Tap Flow
1.Ignite the burner that should be
adjusted, turn the knob to the reduced
position, pull and take the knob off.
2. With a screwdriver, make the tap
reduced flow adjustment from the
injector that is on the gas tap (only
the head is visible with the bolt shape).
It is sufficient to tight to screw
completely, in butane/propane gas.
For the natural gas, you should turn
the screw counter-clockwise once. The
normal length of a straight flame in
the reduced position should be 6 -
7mm.
If the flame is higher than the desired
position, turn the screw clockwise. If
its smaller to the opposite.
For the last control of the burning of
the cooker, bring the cooker high-
flame and reduced positions and check
whether the f l a m e i s o n o r o f f .
