Sound field
MIX 2CH
A, ▼,
ENTER
CH SELECT
DVD
VOLUME
- +
SUBWOOFER
LEVEL
□□PLII
TEST
You may experience a reduction in sound quality when these sound
field systems are used with some sources. If this occurs, turn the
sound field system off.
Dolby Digital and DTS
• Dolby Digital and DTS are digital encoding systems used on DVD
to carry surround sound. Both were originally developed for use in
cinemas.
•This unit automatically recognizes and decodes these systems.
Software encoded with DTS can
be identified with this mark.
D I G I T A L
Software encoded with
Dolby Digital can be iden­
tified with this mark.
□ □I DOLBY I
TAL
S U R R O U N D
Play a Dolby Digital or DTS source.
The Dolby Digital or DTS indicator lights.
■ To down-mix Dolby Digital or DTS (multiple
channel) signals to 2 channels
While stopped
Press [MIX 2CH].
MIX 2CH
To cancel, press [MIX 2CH] again.
• During play, pressing and holding the button also turns the setting
on and oft. (Press and hold again to cancel the setting.)
When “D.MIX” is flashing nwigii
The DVD-Audio contains multiple-channel signals that cannot be
down-mixed.
Dolby Pro Logic II
The Dolby Pro Logic II processor works not only on sources
recorded with Dolby Surround, but also on any stereo source.
1
Press [□□PLII].
Each time you press the button:
MOVIE^MUSIC^OFF
t______________________I
MOVIE: Use this mode when playing movie software,
especially video tapes, recorded in Dolby Surround.
MUSIC: Adds surround effects to stereo sources.
2
Play a Dolby Surround or stereo
source.
This feature does not work for some discs.
Speaker level adjustments
Adjust the level of the speakers so they are the same apparent
level as the front speakers where you would normally be sitting and
listening (L, R ^ below).
Preparation
Press [DVD].
1 While stopped
Press [TEST] to output a test signal.
Lch: Front left
Cch: Center
Rch: Front right
RSch: Right surround
LSch: Left surround
2 Press [VOLUME, -F] or [—] to set the volume level normally
used for listening.
3 Press [A] (to increase) or [V] (to decrease).
C, RS. LS: -6dBto-F6dB
To stop the test signal, press [TEST] again.
■ To adjust speaker level during play
1 Press [CH SELECT] to select the speaker.
L, Rch-^Cch^RSch^LSch^SWch
t________________________ I
SWch: Subwoofer
•You can only adjust SWch if the disc inciudes a subwoofer
channel.
2 Press [A] (to increase) or [V] (to decrease).
L, R: (• below)
C, RS, LS: -6dBfo-F6dB
SW:
-10 dB to-F10 dB
<n
c
o
ss
u
&
flj
3
o-
■Q
c
3
0
1
<c
■Q
C
3
o
(0
Balance
You can adjust the balance of the front speakers.
1 Press [CH SELECT] to select “L” or “R”.
2 Press [◄,►].
•When testing signal, you can also adjust the “L” or “R” balance of
the front right and left speakers by pressing [◄, ►].
You can adjust subwoofer level by pressing [SUBWOOFER LEVEL],
