Other speaker setup options
Attatching to a wail
(Center and surround speakers only)
The wall or pillar on which the speakers are to be attached should
be capable of supporting 5 kg per screw.
2
Screw a screw (not included) into the
wall.
1
Remove the stand.
BEFORE REMOVING THE STAND
•Take the speaker cable out of the stand’s hole if it is
threaded through.
• Lay the speaker on a soft cloth.
Unscrew the screw with a Phillips-head screwdriver.
3
Fit the speaker securely onto the
screw with the hole.
Fitting speaker stands (optional)
Preparation
Remove the stand (• step 1 above).
Ensure the stands meet these conditions before purchasing them.
• Observe the diameter and length of the screws and the distance
between screws as shown in the diagram.
•The stands must be able to support over 5 kg.
•The stands must be stable even if the speakers are in a high posi
tion.
5 mm
pitch 0.8 mm
7 to 10 mm
Keeping the cables out of the way
Pass the cables through the holes in the stand to keep them out of the way.
Notes on speaker use
•You can damage your speakers and shorten their useful life if you
play sound at high levels over extended periods.
• Reduce the volume in the following cases to avoid damage.
-When playing distorted sound.
-When the speakers are receiving howling from a record player,
noise from FM broadcasts, or continuous signals from an oscil
lator, test disc, or electronic instrument.
-When adjusting the sound quality.
-When turning the unit on or off.
If irregular coloring occurs on your television
These speakers are designed to be used close to a television, but
the picture may be affected with some televisions and setup
combinations.
If this occurs, turn the television off for about 30 minutes.
The television's demagnetizing function should correct the
problem. If it persists, move the speakers further away from the tele
vision.
Caution
• Use the speakers only with the recommended system.
Failure to do so may lead to damage to the amplifier
and/or the speakers, and may result in the risk of fire.
Consult a qualified service person if damage has oc
curred or if you experience a sudden change in per
formance.
• Do not attempt to attach these speakers to walls using
methods other than those described in this manual.
RQT6924
