STEP3
Television
Video cable
I
t
q>
«
■ Sì
■I
CO
I Connecting a television with a VIDEO IN terminal
Connect directly to your television.
Do not connect the unit through a video cassette recorder, be
cause the picture may not be played correctly due to the copy
guard.
For the United Kingdom, Continental Europe and Russia
Use the RCAJ adaptor (included) if your televi
sion has a 21-pin SCART terminal. You do not
have to connect anything to the AUDIO termi
nals.
VIDEO
OUT
ÎÎfci:
0
Video cable
(included)
* .4
.
• * •
Video terminal
^^=aiz>
III
ak To your
^ television
RCAJ adaptor
Audio terminals___________
y
Connecting a television with COMPONENT VIDEO terminal
For Southeast Asia, Australia and N.Z.
Television’s COMPONENT VIDEO IN terminal
YP
b
P
r
T
Video cable
(not included)
0
Y P, P=
«S : l
y Jk o ,
n ^ yt) №
COMPONENT VIDEO OUT terminal
These terminals can be used for either interlace or progressive output
and provide a purer picture than the S VIDEO OUT terminal. Connec
tion using these terminals outputs the color difference signals (P
b
/P
r
)
and luminance signal (Y) separately in order to achieve high fidelity in
reproducing colors.
•The description of the component video input terminals depends on
the television or monitor (e.g. Y/P
b
/P
h
, Y/B-Y/R-Y,
Y/C
b
/C
r
).
Con
nect to terminals of the same color.
To enjoy progressive video
•Connect to the component video (480P) input terminals on a television compatible with this unit’s copy guard system. (Video will
not be displayed correctly if connected to an incompatible television.)
• Press [PROGRESSIVE] so “PROGRESSIVE” appears on the display (• page 13).
•All televisions manufactured by Panasonic and that have 480P input connectors are compatible. Consult the manufacturer if you
have another brand of television.
Connecting a television with an S-VIDEO IN terminal
Television’s S VIDEO IN terminal
S-Video cable
(not included)
S VIDEO OUT terminal
The S video terminal achieves a more vivid picture than the VIDEO
OUT terminal by separating the chrominance (C) and luminance (Y)
signals. (Actual results depend on the television.)
á
RQT6924
^ ^
S’VIDEO
OUT -
