Spray-extraction (wash-vacuuming) of
hard surfaces, tiles, carpets and upholstery

Information and safety instructions for use
Make sure that all items to which you are

going to apply a hot or cold detergent solution
are suitable for this method of cleaning.

• Do not use the cleaner on parquet floors. Moisture

could penetrate the wood and damage the floor.

• Before wet-cleaning carpets, the entire area to be

cleaned is to be thoroughly vacuumed.
Do not wet-clean delicate, hand-woven or
non-colourfast carpets.
For test purposes, apply a little detergent solution to
a white cloth and rub a concealed area of the
carpet with this cloth. If there are no traces of colour
on the cloth, it may be assumed that the carpet is
colourfast. Should colour rub off onto the cloth, the
carpet must not be wet-cleaned.
Should you be unsure, consult a carpet dealer.
If the carpet has been shampooed at an earlier
juncture, this may result in considerable foaming in
the soiled-water tank when the THOMAS wash-
vacuum-cleaner is used for the first time. To prevent
further foaming, pour 1/2 a cup of vinegar into the
soiled-water container.
Should foam emerge from the air outlet, switch the
appliance off immediately and empty the soiled-
water tank.
Strong foaming is no longer possible after cleaning
once with THOMAS ProTex cleaning concentrate, as
this agent contains a special foam inhibitor.
Do not walk on the carpet as long as it remains
damp.
The room should be well ventilated during and after
cleaning, to enable swift drying.

General proparation

A Pull out the plug and lift off the motor

block (2).

B

When using the appliance in the spray-extraction
mode, ensure that the extraction liquid tank (28) is
inserted in the collecting bin.

N Pour the cleaning concentrate into the sprayer

tank (28) and fill up with water.
For hard floor cleaning, use the
ProFloor cleaning concentrate.
For carpet and upholstery cleaning, use
the ProTex cleaning concentrate.
For information on application and dosing, please
refer to the label on the cleaning concentrate bottle.
Use lukewarm water (max. 30°C) only.

L

Detach the cleaning solution tube (37) from its
fixture in the motor block (2).

O While putting the motor block (2) back on the

collecting bin, let the cleaning solution tube (37)
dangle down into the cleaning solution.

D Secure the motor block on the collecting bin by

means of both snap-on fasteners (3).

Connecting the flexible hose and delivery tube

P

Slide the spray diffusor control (17) into the fixture
provided on the suction tube. Then insert the
handgrip (11) in the suction tube. Attach the
delivery tube (19) to the flexible hose (13) by
means of the plastic clips (15).

E

Then insert the flexible hose (13) in the suction
socket (8) in such a manner that the markings on
both correspond and the button audibly clicks
into place.

Q Subsequently, insert the delivery tube (19) firmly

into the coupling piece (5) on the motor block (2).
Attention: During working with hot water the
coupling (5) gets hot.
Now attach the second suction tube (the one with
fixture studs) to the p suction tube which is
already mounted.
Take the suitable nozzle and assemble it
according to the illutration

W

and

S

.

– Carpet-spray-extraction-nozzle (18) incl. hard

floor aadaptor (22) for cleaning of hard floors
and tiles

– Carpet-spray-extraction-nozzle (18) for

cleaning of carpet floors

T

Attach the delivery tube (12), which is mounted on
the nozzle, by the coupling piece (39) to the spray
diffusor control (17) and secure by turning the
coupling piece (39).
Then attach the delivery tube (12) to the suction
tubes by means of the smaller tube clips (16).
The control knob on the appliance must be set
at ”0”.

G Plug the appliance into a mains socket.

The appliance is now ready for use.

Set-up wash-vacuuming

15

The spray-extraction system:
• sprays pressurised jets of cleaning solution
• breaks down dirt and cleanses deep into the fibres
• extracts dirty water powerfully

and lifts up carpet pile.

All in a single operation.

suction tube

delivery tube

direction of work

extracts and

raises

sprays

dissolves and cleanses
