Congratulations on your new
purchase!
Enjoy your appliance to the full through
correct usage.
Areas of application
• Scrubbing of hard floors with hot water.
• Spray-vacuuming for deep cleaning and stain
removal of carpeting, hard floors, and upholstery,
i.e. as wash-vacuum cleaner.
• Wet vacuuming, i.e. vacuuming water and other
spilt liquids.
• Vacuuming of carpeting, hard floors, upholstery,
etc. with all the benefits of modern floor vacuuming
technology.
Unpacking the appliance
Unpack the appliance from the carton, remove any
packaging and identify the following parts and
functions in the diagrams at the beginning of this
booklet to gain a better understanding of the
instructions given below.
Assembly instructions
The parts required for the chassis are to be found
loosely packed in the carton.
Assembling the castor wheels
A Undo the snap-on fasteners (3) and lift off the
motor block (2).
B
Take out the extraction liquid tank (28) and
cleaning solution. Turn the collecting bin (1) upside
down, i.e. with the opening facing the floor.
C To facilitate assembly, we recommend lightly
greasing the pegs at both ends.
First insert the pegs (3) in the base of the collecting
bin (1), then push them in, together with the
castors, as far as they will go.
Turn the collecting bin (1) back over onto the
castors (4) and check that these have been
correctly assembled by moving the collecting bin
(1) back and forth in all directions.
Fitting the motor block
D Place the motor block (2) on the collecting bin (1),
making sure that the surfaces of both parts
correspond. Secure the motor block (2) by means
of both snap-on fasteners (3).
Connecting the flexible hose
E
Insert the flexible hose (13) in the suction socket (8)
in such a manner that the markings on both the
suction socket and the hose connecting piece
correspond and the button clicks into place.
Remove the hose by turning the hose connecting
piece and slowly with drawing the hose.
Then attach the desired accessories.
Suction tube holder
F
The suction tubes (14) complete with accessories
and flexible hose (13) can be hooked into the
fixtures at the back of the appliance.
Cable storage
G After use, the mains cable (1) can be wound
loosely in the hand and hung over the notch in the
carrying handle, as shown in the illustration.
Changing the filter
Always pull out the plug before changing
the filter!
NOTE!
Hygienic filter change and emptying of the
collector bin.
Emptying the collector bin and charge of all filter
typesused in the vacuum cleaner (e. g. foam-/paper
filters, paper filter bags, etc.) can be done hygienically.
To this end, please use the hygienic gloves included in
the delivery.
Replacement gloves are readly, available at relevant
supply stores.
Motor protection filter
J
After each wet suction and spray extraction
process, check the motor protection filter (33) for
contaminations and clean if required. For this,
open the float valve (38) in the direction of the
arrow, and take the motor protection filter from
the suction opening. Replace the cleaned or new
filter and then reassemble the float valve to the
motor block.
Paper filter bag
K
Place the filter bag (34) inside the collecting bin (1),
making sure that the opening located in the
cardboard inlay (35) is placed in line with the
suction socket (8).
Then press the filter bag (34) evenly around the
sides of the collecting bin (1).
THOMAS paper filter bags are essential when
vacuuming fine dust, e.g. soot, ashes, sawdust or
cement. However, they are also recommended for
normal use, as they not only improve the retention
of dust, but also make filter changes more
hygienic.
