What
’s What
Display unit
1 Built-in speaker
Outputs the sound from a device connected
to this unit.
! Audio does not output from the built-in
speaker when headphones are con-
nected.
2 Ambient light sensor
Senses ambient light. This system automati-
cally adjusts the brightness of the display to
compensate for ambient light.
3 SRC/POWER button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
Press and hold to turn the unit off.
! This button is not effective when select-
ing FRONT in POWER. C. (Refer to Set-
ting the power control function on page
12.)
4 VOL DOWN/VOL UP buttons
Press to increase or decrease the volume.
Press to change the settings when the
setup menu or the picture adjustment
menu is displayed.
5 WIDE/MENU button
Press to select a desired mode for enlarging
a 4:3 picture to a 16:9 one.
Press and hold to display the picture adjust-
ment menu.
Press and hold to display the setup menu
when the unit is off.
6 Headphone jack (3.5 mm stereo jack)
Use to connect headphones.
2 3 5
1
4
6
Operating this unit
En
8
Section
03
