USER’S MANUAL
18
6. REMOTE CONTROLLER (RC) — CONTROLS AND FUNCTIONS
a
STANDBY: Standby selection
b
FL+: Front Left Channel Level Upward Adjustment Button
c
FL-: Front Left Channel Level Downward Adjustment Button
d
RL+: Rear Left Channel Level Upward Adjustment Button.
e
RL-: Rear Left Channel Level Downward Adjustment Button
f
R-DLY-: Rear Channel Delay Time Downward Adjustment Button
g
OPTICAL: Optical Input Selection
h
DR: Dynamic Range Selection
i
LISTEN: 2.1CH or 5.1CH or Stereo or PLII MUSIC or PLII MOVIE
Selection.
j
VOL-: Volume Downward Adjustment Button
k
DOWN: Frequency Tuning Downward Adjustment Button
l
TUN: Enter Radio
m
AM/FM: Band Selection Button
n
BASS -: Bass Output Down
o
TREBLE -: Treble Output Down
p
C+: Center Channel Level Upward Adjustment Button
q
FR+: Front Right Channel Level Upward Adjustment Button
r
C-: Center Channel Level Downward Adjustment Button
s
FR-: Front Right Channel Level Downward Adjustment Button
t
SW+: Subwoofer Channel Level Upward Adjustment Button
u
RR+: Rear Right Channel Level Upward Adjustment Button
v
SW-: Subwoofer Channel Level Downward Adjustment Button
w
RR-: Rear Right Channel Level Downward Adjustment Button
x
C-DLY+: Center Channel Delay Time Upward Adjustment Button
y
TEST: Noise Sequencer Button — To Test System Connection and
Channel Balance
26
R-DLY+: Rear Channel Delay Time Upward Adjustment Button
27
C-DLY-: Center Channel Delay Time Downward Adjustment Button
28
COAXIAL: Coaxial Input Selection
29
LINE: Line Input Selection
30
VOL+: Volume Upward Adjustment Button
31
MUTE: Muting Selection
32
DSP: DSP Sound Field Selection
33
UP: Frequency Tuning Upward Adjustment Button
34
MEMORY: Station Memory Button
35
CH+: Preset Channel Upward Adjustment Button
36
CH-: Preset Channel Downward Adjustment Button
37
MO/ST: Stereo or Mono FM Radio Selection
38
BASS+: Bass Output Up
39
TREBLE+: Treble Output Up
How to use the remote control
Before using the remote controller, please insert correct type of batteries into the battery compartment. The remote
controller uses 2 x 1.5 V/AAA batteries. Please insert the batteries as indicated below.
• Remove battery compartment cover.
• Insert 2 batteries as per the polarities marked inside the battery compartment.
• Replace the battery cover.
