Operation manual
21
AV SYSTEM
14. Middle tone key (MIDDLE)
Press this key and turn the VOLUME/ADJ switch to adjust middle tone level.
(Refer to Fig.18 )
Adjustment range: from 14dB to +14dB, step is 2dB.
15. Suwoofer level key (SW)
Press this key and turn the VOLUME/ADJ switch to adjust subwoofer channel
level. (Refer to Fig. 19 )
Adjustment range: from 15dB to 0dB,step is 1dB
16. Right surround channel level key (R SUR)
Press this key and turn the VOLUME/ADJ
switch to adjust right surround channel level .
(Refer to Fig. 20 )
Adjustment range: from 15dB to 0dB,step is 1dB.
17. Right front channel level key (R FRONT)
Press this key and turn the VOLUME/ADJ
switch to adjust right front channel level .
(Refer to Fig. 21 )
Adjustment range: from 15dB to 0dB,step is 1dB.
18. Mute key (MUTE)
Press this key can mute the unit and the screen displays characters «— ».
Press the button again or turn VOLUME/ADJ switch
and the unit will be back out of mute mode.
(Refer to Fig. 22)
