ENGLISH
11
Cannot read disks Disk is not loaded Load disk
Disk is loaded with label down Examine position of disk in the tray (label should be up)
There is condensation inside player Leave DVD player without disk for one hour
Microphone is not
working Microphone is switched off Connect a microphone and switch it on
Microphone volume is too low Adjust microphone volume level
Remote control is not
working Remote control is not directed to player Direct remote control to player
Distance between remote control and layer is more then 8
meters Make distance between remote control and layer shorter
Remote control batteries are dead Replace both batteries
Some system functions
are not working Wrong sequence of buttons have been pressed Repeat operation once more according to recommendation
contained in this manual.
Specifications
Power
110-40 V, 50/60 Hz
Power consumption 1 W
Dimensions 6x0x41 mm
Weight 1540 g
Operating temperature from 5°С to 5 °С
Operating moisture from 5% to 90%
Color system NTSС / PAL
Data format Supported formats: DVD, DVCD, SVCD, VCD, CDDA, МРЗ, WMA, HDCD, JPEG, KODAK PICTURE CD
Playback of digital video in MPEG4 (DivX) format
Medium type
DVD, DVD-R/-RW/+R/+RW, CD-R/-RW
Digital-analogue converter 19 kHz / 4-bit
Video output
1Vp-p (75 Ohm)
S-Video output: Y: 1Vp-p (75 Ohm) С: 0,86Vp-p (75 Ohm)
Audio output .0 Vt 5.1 Channel
Digital output of audio signal 0,5Vp-p (75 Ohm)
Jacks
CVBS, S-VIDEO, Y Cb/Pb, Cr/Pr, SCART
Frequency range CD: 0Hz-0kHz (EIAJ), DVD: 0Hz-44kHz (96 kHz PCM), 0Hz-kHz (48kHz PCM)
Noise level ~-80dB
TDH <0,01%
Dynamic range ~80dB
Remote control
Transmitter
Infrared radiation
Battery  batteries ААА
The manufacturer reserves to itself the right to change the design and the technical characteristics of the unit without a prior notice.
. Recycling
“This product is marked by the symbol of the selective sorting, relating to the electrical and electronic component scrap. That means
that the product must be taken by a selective system of collection in accordance with European directive 00/96/CE in order to
be able either to be recycled or to be dismount in order to reduce any environmental impact. Attention! The electronic products
not having been the subject of a selective sorting are potentially dangerous for the environment and human health because of the
potential presence of dangerous substances.”
The manufacturer reserves the right to make changes to the characteristics of the device without prior notice.
The service life of the device is five years.
Guarantee
Details regarding guarantee conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be
produced when making any claim under the terms of this guarantee.
This product conforms to the EMC-Requirements as laid down by the Council Directive
89/6/EEC and to the Low Voltage Regulation (/7 EEC)
