Features
Class ''AB'' Technology MOSFET Power Supply
Remote turn-on of the amplifier via car radio
Continuously Variable 12dB/Octave High Pass & 12dB/Octave Low Pass Crossover
Enhanced Bass Boost 0/12dB @50Hz
Regulator for input sensitivity
Bridgeable mode
Overload, Thermal, Short Circuit Protection
Power & Protection indicator
Precautions: Read First!
If after reading the direction you feel uncomfortable about installing the amplifier in your car, or not
equipped or competent to do so, you should have the amplifier installed by an authorized installer.
It's your car!
Negative battery terminal must be disconnected before any electrical connections are made.
Be sure choosing a location that provides substantial ventilation for the amplifier.
The most preferred locations would be in your car's trunk, under the front seats or on the back wall of
a truck.
The location chosen should provide at least 2" of clearance above the amplifier for adequate
ventilation.
If the amplifier is to be mounted vertically be sure that it is in a place where adequate air will flow
along the length of its heat sink fins for cooling.
NEVER mount the amplifier up side down; this will cause the heat to rise back into the amplifier
causing thermal shutdown or possible permanent damage.
NEVER mount the amplifier in a location that is subject to direct sunlight or exposed to moisture.
Be sure to mount the amplifier to a strong, solid surface, which will not give way under the stress of a
sudden stop or accident.
Make sure that the mounting screws will not penetrate the gas tank, brake and fuel lines, wiring or
other critical parts of your car when installed.
NEVER operate the amplifier without the proper power and ground wire 10 gauge minimum.
NEVER operate the amplifier without proper fusing. Fuse holder must be located with in 0.5 meters
from the battery. This fuse is to protect the car not the electronics. In case of a short, the fuse will
blow instead of the wire burning up. Using other than the recommended fuse ratings at the battery
and at the amplifier may cause damage to the amplifier and will void your warranty.
