SoundMax SM-SA1004 - Инструкция (Страница 13)

13
Specification
MODEL SM-SA1004
RMS Power @ 14.4 DC
4 x 100W at 4 0hms
4 x 190W at 2 0hms
2 x 360W at 4 Ohms (bridged)
Maximum power 800 W
Loudspeaker impedance (stereo) 2-8 Ohms
Frequency response 10 - 25 000 Hz
Total harmonic distortion 0.01%
Stereo separation 50 dB
Signal to Noise Ratio 98 dB
Input sensitivity 0.2V - 7V
Input impedance 10 KOhms
Low-pass filter 50-250 Hz
High-pass filter 60Hz – 1.2kHz/100Hz - 2.2kHz
Bass boost (0dB~12dB)
Power supply +12V, Negative Ground
Fuse rating 30A x2
Dimensions: WxHxL 365 x 64 x 240 mm
Weight 1.8 Kgs
Note: Specifications & design subject to change without notice for improvement. The pictures have been
done for reference and can be different from real units.
