Seated Row Assembly Guide : Assembling the Equipment
11
Installing the Center Upright Assembly
Attaching the center upright assembly and the accompanying seat mechanism
completes the frame of the equipment.
Note: Different screw and washer sizes are used to secure the two parts of the
center upright assembly.
To attach the center upright assembly:
1. Position the assembly on the base frame and against the crossbar as
shown in the following figure.
Figure 6: Center upright assembly attachment
2. Place two M12 x 35 mm socket head cap screws and two 13 mm flat
washers into the screw holes in the base frame. Partially tighten the
fasteners.
3. Place two M10 x 30 mm socket head cap screws and two 11 mm flat
washers into the screw holes in the crossbar. Partially tighten the
fasteners.
4. Check that the frame is correctly aligned, then tighten all fasteners
completely.
