Seated Row Assembly Guide : Getting Started 3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fastener
Quantity
Buttonhead cap screw (M8 x 15 mm) 1
Socket head cap screw (M12 x 35 mm) 14
Flat washer (9 mm internal diameter) 7
Set screw (M8 x 6 mm) 6
Flat washer (13 mm internal diameter) 14
Flat head hex cap screw (M10 x 25 mm) 4
Flat head hex cap screw (M8 x 15 mm) 4
