Installation/Connection Operation
Control elements
Front panel
1. PWR/OFF/TFT button
2. NEXT button
3. TA button
4. SCN button
5. AF button
6. MOD/MUT button
7. IR sensor
8. TFT display
9. OPEN button
10. USB port
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20 21 22 23
11. BND/NP button
12. PREVIOUS button
13. SELECT button/VOLUME regulator
14. PTY/PLAY/PAUSE button
15. AUDIO TYPE/APS button
16. CLK button
17. 1/OSD/LEFT button
18. 2/RPT/RIGHT button
19. 3/INT/UP button
20. 4/RDM/DOWN button
21. 5/STOP/ENTER button
22. 6/SET/PAU button
23. AUX input
Inner panel
1 2 3 4 5
1. Disc loading slot
2. SD/MMC memory card slot
3. RESET button (hole)
4. Panel status indicator
5. EJECT button Pressing RESET hole will erase the clock
setting and stored stations.
Panel status indicator lights up when you flip
down the panel and flashes when you remove
the panel.
