Operation Operation
- - -
In the menu, touch the item of the mode you
need to select the corresponding mode. Touch
the arrow icon in the right part of the screen to
switch between the 2 menu pages.
The DVD, USB and SD modes are only
available when a disc, USB or SD/MMC card is
inserted into the unit.
Navigation (option)
• To enable navigation mode, touch NAVI
button in the main menu. To enable or disable
NAVI mode you can also press
/MAP button
on the panel.
• Insert Navigation memory card into the
Memory card slot of the unit before enabling
navigation mode. To access the slot, open
the front panel. The device will warn you if the
memory card is not properly inserted into the
card slot.
• For more details about operations with
navigation program, please read the instruction
manual to the navigation software. You can
download the quickstart guidance and full
instruction manual for the navigation program
from the web site of the navigation software
manufacturer.
Angle setting
Press repeatedly TILT button to adjust the
desired angle of the monitor.
Please do not adjust the monitor tilt
manually, otherwise it can get damaged.
Monitor in/out
Press repeatedly IN/OUT button on the front
panel to adjust the monitor in/out position when
the monitor is opened.
AV in jack
AV jack is intended to receive audio and video
signals by connecting to external device.
Subwoofer
Connect a subwoofer to this unit using the
Subwoofer output of this unit. For subwoofer
operation an external amplifier is required.
Dual zone function
DUAL - dual zone function enabling user to
listen to radio or watch TV in the front zone,
and at the same time play audio or video from
disc, USB or memory card.
For Dual zone en external monitor with is
required having its own acoustic system and
possibility of volume adjustment.
Press and hold SEL button on the front panel
or press DUAL button on the RC to select
between C-DUAL (buttons perform operations
for the current mode of the front zone) or
D-DUAL (buttons perform DVD functions).
System setup
When you select SETTING mode, the menu
will be displayed, in which you can touch any
item to select corresponding setting page:
