6
CAUTION
• Switch off the power supply before cleaning.
• Do not touch the aluminium fin, sharp parts may cause injury.
2
5
6
7
1
4
3
8
1 INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2 FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it securely.
3 RECEIVER
4 ALUMINIUM FIN
5 HORIZONTAL AIRFLOW DIRECTION LOUVER
• Manually adjustable.
WARNING
Be carefull not to insert your fingers into
the unit to avoid injuring by cross-flow fan.
6 VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
7 AUTO OFF/ON BUTTON
• Use when remote control is misplaced or malfunction.
Action Mode
Press once. Auto
Press and hold until 1 beep is heard, then release. Cooling
• To turn off, press the AUTO OFF/ ON button again.
Procedure of switching OFF/ON signal receiving sound:
1. Press and hold “AUTO OFF/ON” button for
approximately 10 seconds until you hear double beep
sound.
2. Repeat above step within 60 seconds , and then signal
receiving sound will be switched OFF/ON.
Procedure of switching OFF/ON auto restart control:
1. Press and hold “AUTO OFF/ON” button for
approximately 15 seconds until you hear triple beep
sound.
2. Repeat above step within 60 seconds , and then auto
restart control will be switched.
8 AIR FILTERS
• Clean the filters regularly.
• Wash/rinse the filters gently with water to avoid damage
to the filter surface.
• Dry the filters thoroughly under the shade, away from
fire or direct sunlight.
• Replace any damage filter.
INDOOR UNIT
WASHING INSTRUCTIONS HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance have to be carried out at regular intervals.
Please consult authorized dealer.
NOTE
• If chemical cloth is used to wipe the unit, instruction for
the cloth should be followed.
