ENGLISH
9
INDOOR UNIT
CAUTION
• Switch off the power supply and unplug before cleaning.
• Do not touch the aluminium fi n, sharp parts may cause injury.
2
3
7
8
1
4
9
10
11
CLEANING INSTRUCTIONS
CLEANING INSTRUCTIONS
HINT
HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance has to be carried out at regular intervals.
Please consult authorized dealer.
9 , 10 , 11
e-ion AIR PURIFYING
SYSTEM
• Do not touch during operation.
5
HUMAN ACTIVITY SENSOR
• Do not hit or violently press the sensor or
poke it with a sharp object. This can lead to
damage and malfunction.
• Do not place large objects near the sensor
and keep away heating units or humidifi ers
from the sensor’s detection area. This may
lead to sensor malfunction.
1
INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2
FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it
securely.
3
REMOTE CONTROL RECEIVER
4
ALUMINIUM FIN
5
HUMAN ACTIVITY SENSOR
6
HORIZONTAL AIRFLOW DIRECTION LOUVER
• Manually adjustable.
7
VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
8
AUTO OFF/ON BUTTON
• Use when remote control is misplaced or a malfunction
occurs.
Action
Mode
Press once.
Auto
Press and hold until 1 beep is heard,
then release.
Cooling
Press the button to turn off.
9
e-ion CHARGING WIRE
10 e-ion FILTERS
• Clean the fi lters regularly.
• Wash/rinse the fi lters gently with water to avoid damage
to the fi lter surface.
• Dry the fi lters thoroughly under the shade, away from
fi re or direct sunlight.
• Replace any damaged fi lters.
11 ACTIVE e-ion GENERATOR
Clean with dry cotton bud.
• Active e-ion generator cleaning is
recommended every 6 months.
5
6
