Installation

Preparation

Installation Hardware

• Before installation, check the radio operation with

antenna and speakers.

• Disconnect the cable from the negative (-) battery

terminal (see caution below).

• Unit should be installed in a horizontal position with

the front end up at a convenient angle, but not more

than 30°

^

-t©

30^ or less

Caution: Do not disconnect the battery terminals of

a car with trip or navigational computer since all

user settings stored in memory will be lost.

Instead take extra care with installing the unit to

prevent shorts.

I 53 mm

-182 mm-

Dashboard Installation

Installation Opening

The unit can be installed

in any dashboard having

an opening as shown at

right.

The

dashboard

should be 4.5 mm - 6 mm thick in order to be able to

support the unit.

Installation Precautions

This product should be installed by a professional

installer, if possible.

In case of difficulty, please consult your nearest

authorized Panasonic Service Center.

1. This system is to be used only in a 12-volt, DC

battery system (car) with negative ground.

2. Follow the electrical connections carefully (a page

18). Failure to do so may result in damage to the

unit.

3. Connect the power lead (red) after all other

connections are made.

4. Be sure to connect the battery lead (yellow) to the

positive terminal (+) of the battery or fuse block

(BAT) terminal.

5. Insulate all exposed wires to prevent short circuiting.

6. Secure all loose wires after installing the unit.

7. Please carefully read the operating and installation

instructions of the respective equipment before

connecting it to this unit.

No.

Item

Diagram

Q'ty

©

Mounting collar

1

w

Hex. nut (5 mm0)

1

e

Rear support strap

1

®

Tapping screw

(5 mm0 X16 mm)

(f

1

Mounting bolt (5 mm0)

1

®

Power connector

1

Dismounting plate

o

2

Trim plate

1

14

(b) Using the Rubber Cushion (option)

Rear Support Bracket
(Provided on the car)

__ _ _ ^ Rubber Cushion \
i

(

O

p

t

i

o

n

)

\

\

f©(D Mounting Bolt

Mounting Coiiar

CQ-RG133W

Cautions:

• We strongly recommend that you wear gloves for installation work to protect yourself from injuries.

• When bending the mounting tab of the mounting collar with a screwdriver, be careful not to injure your hands and

fingers.

First complete the electrical connections, and

then check them for correctness.(

a

page 18)

The included Mounting Collar

© is designed specially for this

unit. Do not use it to attach any

other model.

Insert

Mounting

Collar

©

into

the

dashboard,

and

bend

the

mounting

tabs out with a screwdriver.

The tabs to be bent vary depending on the car.

To securely install the unit, fully bend a

number of the tabs so that there is no rattling.

Example

^ Tab

'W ^

W"

© Mounting \

C

o"ar \[.i

// /

® Power Connector —

Establish the rear connection of the unit.

After fixing Mounting Bolt t and Power Connector

®, fix the rear of the unit to the car body by either

method (a) or (b) shown on the previous page.

After

installation

reconnect

the

negative (-) battery terminal.

15

H

10

H
