n
General
Power
Turn the key in the ignition until the accessory
indicator lights.
Power on: Press [PWR].
Power off: Press [PWR] again.
Volume
Turn the knob clockwise to increase volume,
and counterclockwise to decrease volume.
1 i n i
I Í “
L J L J L . .
1 D
_____________ I I ___
I
Volume level (0 to 39)
Up
Down
[DISP] (display)
Mute
Press [MUTE] to mute the sound completely.
MUTE indicator
Press [MUTE] again to cancel.
Loudness
Press and hold for more than 2 seconds. [MUTE]
(LOUD) to enhance bass and treble tones at low or
medium volume.
Loudness indicator
Press and hold for more than 2 seconds [MUTE]
(LOUD) again to cancel.
CQ-RG133W
Note: If no operation takes place for more than 5 seconds
in audio mode (2 seconds in volume mode), the display
returns to the regular mode.
Clock Setting
H
Audio Modes
(Bass/Treble/Balance/Fader)
Push [SEL] to select the audio mode.
The 24-hour system is used for the clock.
Initial Time
© Press [DISP] (display).
(Clock display)
AdJ” is displayed when the clock is not adjusted.
[< TUNE], [> TUNE] (Hours, minutes)
(W Turn [VOL] clockwise or counterclockwise to
change each level.
Bass:
ÎR5
default: 0 dB
Adjustable range: -12 to +12 dB (by 2 dB step)
Treble:
default: 0 dB
Adjustable range: -12 to +12 dB (by 2 dB step)
Balance:
R (right speaker) or L (left speaker)
Adjustable range:
Balance center
1 to 15 (by 1 step) (default)
Fader:
F (front speaker) or R (rear speaker)
Adjustable range: 1 to 15 Fader center
(by 1 step)
(default)
Hours
@ Press and hold [DISP] (display) for more than 2
seconds.
RHlsiM
(Hours blink)
© Press [< TUNE] or [> TUNE].
(Hours set.)
Minutes
© Press [DISP] (display).
(Minutes blink.)
t Press [< TUNE] or [> TUNE].
(Minutes set.)
y Press [DISP] (display).
S: IS
(End.)
Note: Press and hold [< TUNE] or [> TUNE] to
change numbers rapidly.
Time Reset
Press and hold [DISP] (display) for more than
2 seconds to activate the time setting mode to reset
the time.
Then, repeat steps ® to ®.
CQ-RG133W
7
H
6
