Страница 47: Testing your magnetic cat flap, En ru no da sv fi, Your petsafe, Cat flap is now ready to use
47
EN
RU
NO
DA
SV
FI
Replacement flaps available online
Magnetic tunnel
The fixed tunnel is an integral part of the mechanism and MUST NOT
be cut or damaged, as it will affect the
operation of the latch mechanism (
Fig. 9).
Operates by magnetism and requires
no batteries.
Tunnel extensions
(optional)
The cat flap is designed to fit any depth of hole. It is recommended that
the tunnels be glued on to the frame and each other
(Fig. 10).
The fixed tunnel supplied with the cat flap is 45 mm. To purchase
additional tunnels at a depth of 47 mm and to make up the depth of the
hole in your wall, visit the PetSafe
®
website
www.petsafe.net.
Using the 4-way lock
The 4-way lock allows you to control your cat’s access
in and out of your home.
It is a good idea not to use the 4-way lock until your pet is thoroughly
familiar with using the door. Your pet may become confused as to why
you have installed it.
Testing your magnetic cat flap
Position the 4-way lock in the ‘in or out’ position. Place collar key on
centre of tunnel. Let go of collar key and push door with your hand to
open (
Fig. 11). Do not force flap open with magnet in hand (Fig. 12). Fit
one hanging key to your cat’s collar (
Fig. 13).
FIG.9
FIG.11
FIG.12
FIG.13
Your PetSafe
®
cat
flap is now ready
to use.
FIG.10
• In only
• Out only
• In or Out
• Fully locked
Fixed tunnel included
Additional tunnel
extensions available
4-way locking system
