Fitting your cat flap
Your PetSafe
®
cat flap is fitted with the red 4-way lock on the inside of
your house.
Temporarily place the cat flap in the hole and position the outside cover
on the outside of the house. From the outside mark screw holes through
the holes in the outside cover
(Fig. 6).
Remove the cat flap and drill the holes with a 5 mm (
3
/
16
”) drill bit (
Fig. 7).
FIG.6 FIG.7
Replace the cat flap in the hole and from the outside screw into place
(Fig. 8).
If the screws are too long they may need to be cut down to match the
depth of your door. Using over long screws may damage the cat flap.
The screws should be removed from the cat flap before cutting. File down
to ensure there are no sharp edges.
Push fit the 4-way locking turning dial into place (
Fig. 8).
Finally, cover the screw holes with the blanking plugs on the outside
frame to ensure a neat finish (
Fig. 8).
FIG.8
If fitting into glass, the cat flap is ‘clamped’ to the
glass using two screws from the outside of the house.
