ENGLISH
The 3 Types of Power Supplies
1)
2
)
3)
■
1
2
3
4
AC Adaptor (supplied) to supply power from an AC
mains socket
Car Battery Charger (optional) to supply power from
a Cigarette Lighter Socket
Battery (supplied) (-> 18)
Supplying Power from an AC Mains Socket
Slide the [BATTERY] Lever upward to
open the Battery Compartment Cover.
Insert the battery-shaped connector of the
DC Input Cable Q into the Movie Camera.
Pull back the Cover for the DC Input Cable Slot 0
and lift it. Pass the DC Input Cable through the slot
and close the Battery Compartment Cover.
Connect the other end of the DC Input
Cable to the AC Adaptor.
Connect the AC Mains Cable to an AC
mains socket.
(A):
Hong Kong only
♦ Before disconnecting the AC Mains Cable, set the
[POWER ON/OFF] Switch to [OFF].
♦ If you use the Movie Camera for a long time, it
becomes warm. However, this is normal.
■ Supplying Power from the Cigarette
Lighter Socket in a Car
You can use the optional Car Battery Charger
VW-KBD1E to supply the Movie Camera with power from
the Cigarette Lighter Socket in a car.
In addition, you can also use it to charge the Movie
Camera’s Battery.
♦ After use, be sure to disconnect the Car Battery
Charger from the Cigarette Lighter Socket.
♦ Be sure to start the car engine before you connect the
Car Battery Charger, otherwise the fuse may blow.
♦ Use the DC Input Cable supplied with the Movie
Camera for connecting, not the one supplied with the
VW-KBD1E.
2
)
(siSSn°) LdifixISifiiSiftil
3)
(-M8)
H dd X
aiil
2
^ mx
3
;A):
♦
i & W S l } f i i ± m U Z m
■
M M
[POWER ON/OFF] gfl
lixBiriOFF) »
♦
/igsatrai ■
■ an
♦
(S]#vw-KBDiE?/t
I'J '
t
D
16-
