Panasonic ES-LA93 - Инструкция (Страница 3)

3
English
SPECIFICATIONS
Power source: See the name plate on the product.
(Automatic voltage conversion)
Motor voltage: 3.6 V DC
Charging time: 1 hour
This product is intended for household use only.
Partsidentification












 

a
c
e
b
d
f
g

  

 









A Protective cap
B Outer foil section
1 Foil frame
2 System outer foil
3 System outer foil release
buttons
C Inner blades
D Main body
4 Foil frame release buttons
5 OFF/ON switch
6 Switch lock button
7 LCD panel
a. Used time
b. Battery capacity
c. Charge status
d. Sonic vibration
e. Foil/blade check
f. Clean
g. Battery capacity
8 Appliance socket
9 Trimmer
 Trimmer handle
E Adaptor (RE7-51)
 Power cord
 Appliance plug
F Self-cleaning recharger
(Referred to as the
“Recharger”.)

Cleaning tray
 Detergent cartridge
 Socket
 Water tank cap
 Water tank
 Water maximum line
 STATUS lamp
 CLEAN lamp
 DRY lamp
 SELECT button
 Soft case
H Cleaning brush
I Oil
Operatingenvironmentfortheself-cleaning
recharger
Operating temperature: 15-35 °C
Operating humidity: Less than 95%
If you use the self-cleaning recharger in temperatures outside the
above range, the following problems may occur.
The time it takes to charge the shaver increases.
The recharger stops functioning.
The lifespan of the rechargeable battery shortens. (Only when
you use the recharger in lower temperatures.) In this case, the
indicators on the LCD panel will blink twice every second.
If the indicators on the LCD panel do not glow, wait for a short
•
-
-
-
•
