10
English
Replacingtheinnerblades
1. Press the foil frame release
buttons and lift the outer foil
section upwards as illustrated.
. Remove the inner blades one
at a time as illustrated.
Do not touch the edges
(metal parts) of the inner
blades to prevent injury to
your hand.
3. Insert the inner blades one at
a time until they click as
illustrated.
•
2 3
Cleaningwiththebrush
(A) (B)
1. Clean the inner blades using
the short brush by moving it in
direction (A).
Clean the system outer foil,
the shaver body and the
trimmer using the long brush.
Do not move the short brush
in direction (B) as it will
damage the inner blades and
affect their sharpness.
Do not use the short brush to
clean the outer foils. •
•

Cleaningtheself-cleaningrecharger
Beard trimmings may become attached to the cleaning tray of the
self-cleaning recharger. Follow the steps below to remove them.
We recommend doing this each time you change the detergent
cartridge.
1. Be sure to remove the water
tank and the appliance plug
from the self-cleaning
recharger.
Be careful not to spill the
cleaning liquid.
. Gently wipe off any beard
trimmings attached to the
inside of the cleaning tray with
a cloth or tissue paper
dampened with water.
Clean the corners and
uneven parts of the cleaning
tray with a cotton swab
dampened with water.
•
•
2
Do not pull hard on the rubber blade protector at the bottom of
the cleaning tray. The rubber may come off if you pull hard on it.
It is only necessary to pull it up slightly.
Warning - Do not wash or apply water to the adaptor or self-
cleaning recharger. Failure to observe this may cause electric
shock or result in short circuits. •
•
