Fan Speed / Air Swing Adjustment
Vertical air flow direction
■ Setting automatic air flow directions
COOLING • DRY • AIR CIRCULATION
Automatically it sets to swing up and swing down.
HEATING
During starting of operations and other circumstances when the
air temperature is low, the air flow blows horizontally.
When temperature is high, air flow is blown down, then it starts
swinging.
Louvres adjustment angles
Approximately
50 degrees
●
Adjust the vertical air flow directions by only using the remote
control. (To prevent mistakes, condensation and damage)
●
At the end of operation, the louvres will automatically close up
the air flow outlet vents.
●
The louvres will automatically adjust its air flow angles to
prevent condensation (during COOLING / DRY) and cold air
blowing out (during HEATING).
●
The louvres adjustment range during HEATING and COOLING
/ DRY may not be the same.
You can adjust the
louvres in 5 steps
within these ranges.
●
You cannot change the air flow direction on the duct type.
NOTE
Horizontal air flow direction
●
Manually grip and move the horizontal air flow louvres.
●
The blower fan of the indoor unit is operating at a high speed, hence, be careful not to insert your fingers into
the portion behind the louvres.
●
You cannot change the air flow direction on the duct type.
NOTE
