25
English
03
Basic Featur
es
NOTE
✎
If you turn the TV off while watching in x PIP mode, the
PIP window will disappear.
You may notice that the picture in the PIP window
x
becomes slightly unnatural when you use the main
screen to view a game or karaoke.
While
x Internet@TV is in operation, the PIP function
cannot be used.
PIP settings
x
Main picture Sub picture
Component, HDMI1/DVI,
HDMI2, HDMI3, HDMI4,
PC
TV
PIP (Off / On) ■ : Activate or deactivate the PIP function.
Channel ■ : Select the channel for the sub-screen.
Size ( ■ Х / Г / А / Œ): Select a size for the sub-
picture.
Position (
■ à / – / — / œ): Select a position for the
sub-picture.
Sound Select (Main / Sub)
■ : You can choose the
desired sound (Main / Sub) in PIP mode.
Support Menu
Self Diagnosis
Picture Test (Yes / No) ■ : Use to check for picture
problems and if the problem continues to occur check
the colour pattern.
Sound Test (Yes / No)
■ : Use the built-in melody sound to
check for sound problems.
If you hear no sound from the TV’s speakers,
✎
before performing the sound test, make sure
Speaker Select is set to TV Speaker in the
Sound menu.
The melody will be heard during the test even if
✎
Speaker Select is set to External Speaker or the
sound is muted by pressing the
MUTE button.
Signal Information ■ : (digital channels only) HDTV
channel’s reception quality is either perfect or the
channels are unavailable. Adjust your antenna to
increase signal strength.
Troubleshooting
■ : If the TV seems to have a problem,
refer to this description.
If none of these troubleshooting tips apply, contact
✎
the Samsung customer service centre.
Software Upgrade
Software Upgrade can be performed via a broadcasting
signal or by network connection or downloading the latest
firmware from “www.samsung.com,” to a USB memory
device.
Current Version the software already installed in the TV.
Software is represented as “Year/Month/Day_Version”.
✎
Installing the Latest Version
By USB ■ : Insert a USB
drive containing the
firmware upgrade file,
downloaded from
“www.samsung.com,”
into the TV. Please
be careful not to
disconnect the power
or remove the USB
drive until upgrades are
complete. The TV will be turned off and on automatically
after completing the firmware upgrade. When software is
upgraded, video and audio settings you have made will
return to their default settings. We advise you to to write
down your settings so that you can easily reset them
after the upgrade.
By Online
■ : Upgrade the software using the Internet.
First, configure your network. For detailed
✎
procedures on using the Network Setup, refer to
the “Network Connection” instructions.
If the internet connection doesn’t operate properly,
✎
the connection may be broken. Please retry
downloading. If the problem persists, download by
USB and upgrade.
USB Drive
TV Side Panel
or
Software Upgrade
By USB ►
By Online
By Channel
Standby Mode Upgrade
: Off
Alternative Software ----/--/--_-----
U Move E Enter R Return
Current Version 2010/01/18_000001
