Wash the parts in contact with processed product before
first usage.
Operate the blender so, that the closed/open markings
located on the appliance are well visible.
Operation with ice crusher (Fig. J)
1
Place the container of the mini food processor on firm,
flat and dry surface.
2
Place the disc for ice on the spindle (double – sided
disc), so that the blades provided for operation are on the
top.
3
Place the disc with the spindle inside the mini food
processor container so that the pivot protruding from the
container is inserted into the spindle orifice.
4
Insert the ice crusher container on the fasteners of the
mini food processor. Then lock the crusher container, turning
it until you can feel it is blocked.
5
Place the processed products inside the container not
exceeding MAX level.
When you fill up the crusher container (13) with
appropriate amount of processed product (do not
exceed MAX level) center the spindle (15) (put in the
middle) to enable its proper coupling with the mini food
processor lid (9).
6
Insert the mini food processor lid including the gearbox
into the fasteners of the ice crusher container. Then lock the
lid turning it until you feel it is blocked.
7
Insert the blender drive on such assembled ice
crusher
.
8
Lock the blender drive .
9
Connect the plug into the mains supply outlet.
10
Start�up the appliance pressing TURBO switch of the
blender motor drive.
After operation, switch off the appliance and unplug it
●
from the socket.
Disassembling the ice crusher, proceed reverse to its
●
assembling.
ATTENTION! The ice crusher blades are very sharp.
Be very careful during assembling, disassembling or
during cleaning.
ATTENTION! Never exceed the maximum level of the
ice crusher input.
ATTENTION! Never disassemble the lid from the
container before the disc stops rotating.
During operation of the drive of the blender with the ice
crusher use TURBO function.
Operational tips
Maximum level of input of the ice crusher container
●
corresponds with the capacity of 450 ml.
Shake the appliance in case the products are clogged
●
over the disc.
In case the products get stuck to the inner wall of the
●
mini food processor container hindering or blocking
ejection of grinded product out of the upper container of
the ice crusher:
Switch off the appliance.
–
Remove the drive with the lid and container of ice or
–
other products crusher.
Remove the products out of the mini food processor
–
walls.
Re�assemble the appliance – as defined above,
–
Continue the operation.
Possible usage of the appliance
You can use products (i.e. fruit) grinded with the ice crusher
to prepare ice�cream, yoghurts, desserts.
Recommended granulation level for given
product
Product*
Recommended
gear**
Granulation
level
TURBO
I�II
TURBO
I
* The maximum level of input to the ice crusher container corresponds
with the capacity of 450 ml.
** Do not use the ice and other products crusher longer than 2 min.
Cleaning and maintenance
After each use of the blender drive wash carefully the
●
parts in contact with processed product.
The blender drive, whisk gearbox, mini food processor lid
●
including the gearbox and the food processor base with
dicer shall be cleaned with damp cloth with dish washing
liquid. Do not immerse in water or wash in dishwasher,
as it can result in damage of the appliance!
Wash the mixing attachment mixing clean warm water.
●
Wash manually the metal parts with water with dish
washing liquid, then rinse well.
Do not wash the mixing attachment or other metal parts
●
in dishwasher.
Remove the dirt in gaps or corners with brush for
●
dishwashing.
In respect of long�term usage the elements made of
●
plastic can be discoloured. Do not treat it as a defect.
You can easily remove the carrot juice stains with cloth
●
immersed in edible oil.
After washing the blender accessories dry them and
●
store in dry place.
