Operation with food processor (slicing disc,
chipping and puree disc) (Fig. H)
1
Place the selected disc on the disc driver (double�sided
discs) so that the blades provided for operation are on the top.
2
Insert the accessory inside the container, so that it is
connected with the drive shaft.
3
Insert the permanent guard. The guard can be assembled
inside the food processor container in one position only, so
that the protrusion of the permanent guard is locked inside
the handle of the food processor container.
4
Insert the lid of the food processor into the fasteners of
the container (take care that the lid is fastened with all the
fasteners).
5
Lock the lid.
6
Insert the blender drive (assembling of the drive is
possible only when the container lid is closed). Then lock it.
7
Set the desired gear using the speed control knob.
8
Insert processed products into the lid chute.
9
Hold the pusher to the chute, so that it does not press
the product before start – up of the appliance (push the next
portions of products when the blender drive is in operation /
the disc is rotating).
10
Connect the plug into the mains supply outlet. Then start –
up the appliance pressing the switch of the blender drive.
After operation of the food processor and dicer
(Fig. I)
1
Release the button (or TURBO in case of using this
gear).
2
Remove the plug of the supply cord from the mains
supply outlet.
3
Unlock and remove the blender drive (after the appliance
stops completely).
4
Remove the pusher from the lid chute (in order to open
the lid it is necessary at first to remove/lift the pusher out of
the chute).
5
Unlock and open the lid.
6
Remove the permanent guard (in case of dicer together
with grid).
7
Remove the disc.
8
Unlock the container.
9
Remove the container from the base.
10
Empty the container removing the products.
Operating instructions
Dicer grid
During dicing with grid it is necessary to adjust the pusher
●
pressing power to the set speed of the blender to obtain
better results (well shaped dice).
During dicing big cooked vegetables or soft fruit, cut
●
them in longitude direction into smaller pieces adjusted
to the size of the feed chute.
It is recommended to insert the products onto the feed
●
chute in vertical position so that they fill in complete
space of the chute.
When the container is filled up to MAX level, stop the
●
operation, empty it and collect the scrap accumulated on
the disc.
Chipping and puree disc
During operation with chipping and puree disc it is
●
recommended to apply the blender drive speed 12 or
TURBO.
Insert the processed product into the feed chute, hold the
●
pusher (do not press), switch on the blender drive. When
the appliance is in operation press the pusher with a bit
of power.
When the container is filled up to MAX level, stop the
●
operation, empty it and collect the scrap accumulated on
the disc.
Slicing disc
During operation with slicing disc it is recommended to
●
apply the blender drive speed 12 or TURBO.
It is recommended to insert the products onto the feed
●
chute in vertical position so that they fill in complete
space of the chute.
Insert the processed product into the feed chute, hold the
●
pusher (do not press), switch on the blender drive. When
the appliance is in operation press the pusher with a bit
of power.
When the container is filled up to MAX level, stop the
●
operation, empty it and collect the scrap accumulated on
the disc.
OPERATION WITH ICE CRUSHER
The appliance characteristics
Zelmer hand blender is equipped with ice crusher which is
used for crushing ice and i.e. frozen fruits.
ATTENTION! You can use the crusher only with the
container and lid of mini food processor!
Application of the accessories
Double-sided disc – is used for crushing, grinding ice and
frozen products. The disc is round, the blades are double�
sided. One side, which we recognize by the applied plastic
fifteen� pointed star, fig. 14a is used for first level grinding „I”
(smaller particles of grinded product), the other side is used
for second level grinding „II” (bigger particles of grinded
product) and it is marked with seven�pointed star fig 14b.
Spindle – is used for fixing the disc.
Preparation of the ice-crusher
ATTENTION! Before assembling and disassembling
blender motor drive On the ice crusher, make sure if
the supply cord plug is disconnected from the mains
supply outlet.
