JVC CD Receiver KD-SX947R - Инструкция (Страница 44)

44
ENGLISH
3
Start searching for an ensemble.
When an ensemble is received, searching
stops.
To stop searching before an ensemble is
received, press the same button you have
pressed for searching.
4
Select a service (either primary or
secondary) you want to listen to.
To change the display information while
tuning in to an ensemble
Normally service name is shown on the display.
If you want to check the ensemble name or its
frequency, press DISP (display).
Each time you press the button,
the following information appears
for a while on the display.
To tune in to a particular ensemble without
searching
Before you start....
Press FM/AM (DAB) briefly if CD, CD changer, or
external component is the current source.
1 Press and hold FM/AM (DAB) to select DAB
tuner as the source.
2 Press FM/AM (DAB) repeatedly to select the
DAB band (DAB1, DAB2, or DAB3).
3 Press and hold ¢ or 4 for more
than one second.
4 Press ¢ or 4 repeatedly until the
ensemble you want is reached.
• If you hold down the button, the frequency
keeps changing until you release the button.
5 Press 5 (up) or ∞ (down) to select a service
(either primary or secondary) you want to
listen to.
To restore the FM/AM tuner
Press and hold FM/AM (DAB) again.
Storing DAB services in
memory
You can preset up to 6 DAB services in each
DAB band (DAB1, DAB2, and DAB3) manually.
Before you start....
Press FM/AM (DAB) briefly if CD, CD changer, or
external component is the current source.
1
Select the DAB tuner.
Each time you press and
hold the button, the DAB
tuner and the FM/AM tuner
are alternately selected.
2
Select the DAB band (DAB1, DAB2,
or DAB3) you want.
Each time you press the
button, the DAB band
changes as follows:
Press ¢ to
search for ensembles
of higher frequency.
Press 4 to
search for ensembles
of lower frequency.
Press 5 (up) to select
the next service. (If a
primary service has
some secondary
services, they are
selected before the
next primary service is
selected.)
Press ∞ (down) to select the previous
service (either primary or secondary).
FM/AM DAB
DAB 1
(D1)
DAB 2
(D2)
DAB 3
(D3)
Service name
Ensemble name
Channel number
Frequency
EN43-46_KD-SX947R[EE]f.p65 1/17/03, 12:13 PM 44
