ENGLISH
* 1 When you adjust the bass, treble, or loudness, the
adjustment you have made is stored for the currently
selected sound mode (C-EQ) including “USER.”
* 2 If you are using a two-speaker system, set the fader
level to “00.”
* 3 Normally the control dial works as the volume
control. So you do not have to select “VOL” to
adjust the volume level.
2
Adjust the setting.
3
Repeat steps 1 and 2 to adjust the
other items.
To reset each sound mode to the factory
settings, repeat the same procedure and
reassign the preset values listed in the table on
page 30.
To increase the level or
turn on the loudness
To decrease the level or
turn off the loudness
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
Select the item you want to adjust.
Each time you press the
button, the adjustable items
change as follows:
Indication To do: Range
BAS* 1 Adjust the bass. –06 (min.)
|
+06 (max.)
TRE* 1 Adjust the treble. –06 (min.)
|
+06 (max.)
FAD* 2 Adjust the front R06 (Rear only)
and rear speaker |
balance. F06 (Front only)
BAL Adjust the left L06 (Left only)
and right speaker |
balance. R06 (Right only)
LOUD* 1 Boost low and high
frequencies to
LOUD ON
produce a well- |
balanced sound LOUD OFF
at low volume level.
WOOFER Adjust the 0 (min.)
subwoofer output |
level. 8 (max.)
VOL* 3 Adjust the volume. 00 (min.)
|
50 (max.)
Ex. 1: When you adjust “TRE” (treble)
Ex. 2: When you turn on the loudness
Equalization pattern changes
as you adjust the bass or treble.
VOL
(volume)
BAS
(bass)
TRE
(treble)
FAD
(fader)
BAL
(balance)
WOOFER LOUD
(loudness) (subwoofer)
