33
ENGLISH
DAB AF* 2 Alternative frequency
search
DAB VOL* 2 DAB volume adjustment
LEVEL Level display
DIMMER Dimmer mode
TEL Telephone muting
BEEP Key-touch tone
SCROLL Scroll mode
EXT IN* 3 External component
AUX ADJ Auxiliary adjustment
TAG DISP Tag display
Indications Selectable values/items
Factory-preset See
settings page
46 AF OFF AF ON AF ON
46 VOL–12 — VOL+12 VOL 00
CHANGER LINE IN CHANGER
TAG OFF TAG ON TAG ON
OFF ON ON
AUDIO 2
AUTO
OFF
ONCE
33
34
34
34
34
34
34, 35
* 2 Displayed only when DAB tuner is connected.
* 3 Displayed only when one of the following sources is selected—FM, AM, and CD.
AUDIO 1 AUDIO 2
OFF
AUTO OFF
ON
MUTING 1 MUTING 2
OFF
ONCE AUTO
OFF
34 A.ADJ 00 — A.ADJ 05 A.ADJ 00
When CLOCK is set to ON:
Source
Current
Pressing DISP (display)
indication
Tuner Clock Band appears for about
5 seconds.
CD and Clock “CD” or disc number and
CD-CH track/file number
appear alternately
each time you press the
button.
To select the level meter—LEVEL
You can select the level display according to your
preference.
When shipped from the factory, “AUDIO 2” is
selected.
• AUDIO 1: Shows the audio level indicator.
• AUDIO 2: Alternates “AUDIO 1” setting and
illumination display.
• OFF: Erases the audio level indicator.
To set the clock display—CLOCK
You can set the clock to be shown on the display
when the unit is turned on.
When shipped from the factory, the clock is set to
be shown on the display.
• ON: Clock display is turned on.
• OFF: Clock display is turned off. When
“OFF” is selected, the other
information (see table below)
appears instead of the clock
display (except when “LINE IN” is
selected as the source).
When CLOCK is set to OFF:
Source
Current
Pressing DISP (display)
indication
Tuner Band
Clock appears for about
5 seconds.
CD and “CD” or
CD-CH disc number
