E9
4 MODE SETTING
4-1. OPERATION MODES
There are three operation modes below. One of the operation modes can be selected on the display
screen of the information display of this lens according to usage and preference.
1. Basic mode : Items that can be set and viewed are limited in this mode, and are recommended to
users who do not require sophisticated settings. This product is factory-set to basic
mode.
2. Full mode
: All items can be set and viewed in this mode.
3. Analog mode : This mode is selected when the digital functions are not used at all.
• Switches labeled VTR, RET, IRIS A/M, and IRIS INST control the respective functions. The rocker
switch serves as a regular zoom switch.
• AUX and MEMO switches are disabled.
• To set auto iris gain adjustment, use either display or trimmer operations.
•
Shuttle shot, framing preset, speed preset, and zoom tracking are not available.
This manual describes only the items that can be set on the Top screen in each mode.
For details on how to set them, refer to
“
Information Display Manual
”
in the supplied CD-ROM.
4-2. SETTING ITEMS IN BASIC MODE
The following eight items can be set on the top screen in Basic Mode.
[Trk]OFF
Shtl
A 1
A 2
MENU
Initial Top screen in Basic Mode
IG: 50
A
Fr1P
Fr1P
[I-Tq]H
[Z.M.]
1. Go to MENU screen
2. Auto iris gain settings
3. AUX switch assignment
4. Zoom tracking ON/OFF
5. AUX1 switch assignment
6. AUX2 switch assignment
7. Iris torque settings
8. Zoom curve mode settings
4 MODE SETTING
For details on how to set them, refer to
“
Information Display Manual
”
in the supplied CD-ROM.
