6
Installation
Attention
• Ensure there is sufficient space around the monitor, and install so that air can circulate.
• If its installation location has changed, please perform calibration (for FDU2603WT only).
●
Exterior view
unit : mm
593
15.5
30
15.5
406
86
13.5
3.2
30
25
562
86
45°
58.1
138.5
70
90
90
8-M6
624
550
344
37
37
56
56
456
32
32
Enclosure mounting holes
(4 holes on left/right)
M6
AC power terminal block
AC power connector
DC power terminal block
Output: D-Sub mini 15-pin connector
Input: D-Sub mini 15-pin connector
DVI-D connector
D-Sub 9-pin connector
TOP:For touch panel control
(for FDU2603WT only)
BOTTOM:For monitor control
USB port
(for FDU2603WT only)
Display area
