Checks before starting:
Make sure that an airfilter is installed.
Make sure that air inlet and return air grillages of the outdoor unit are not
blocked by foreign objects.
Cleaning of airfilter
Air filter cleans the air entering the conditioner from dust and foreign
particles. If the filter is contaminated, the conditioner capacity decreases
sharply. If the conditioner is operated permanently, the filter should be
cleaned once per two weeks.
If the conditioner is installed in a room with dusty atmosphere, then the air
filter should be cleaned more often.
If the filter is contaminated heavily, replace it with a new one (air filters may
be purchased by separate order or boug ht i n a shop).
To remove the filter, open the air inlet of the indoor unit panel. Press the
locks to the center and pull the grillages down. Remove the air inlet.
Remove the air filter. Clean the filter with a vacuum cleaner or rinse it in
clean water. If the filter is contaminated heavily, clean it with a soft brush
and wash in diluted washing solution, then dry it in a cool place.
While cleaning the filter with the vacuum cleaner, hold it with
contaminated surface up. While washing the filter in water, hold it with
conta m inated su rface down.
Do not dry the filter in the sun or near a fire.
Settheairfilterto initial position and close an air inlet cover
9.TROBLESHOOTING
Failures and their possible reasons:
Th»fcnd>cntr4kNi not
«firk
iimtnHÊÊtcaÉmfn
lie M
MUti
MmpKni hpcMr «ivir TfW I k r«twi*ton el pewr iiiW
FDMton<Micli
■ fc- ■ ^ A ^ uWOBDQBQrVV ûUMte
10. SERVICE LIFE
Service life of the device is 10 years provided that the respective
installation and operation rules are observed.
Date of the conditioner manufacture is shown in a serial number of the
device. For more details, please, ask a shop assistant.
11. UTILIZATION RULES
Upon expiration of the service life, the device should be utilized in
accordance with norms, regulations and procedures effective in the
place of utilization.
