4. DEVICE DESCRIPTION
The conditioner consists of indoor and outdoor units connected by
pipelines. The conditioner is controlled from a remote control board or
from a control panel of the indoor unit.
Figure 1. Device description
6
5
ENGLISH
5. DELIVERY SET
Complete set of air conditioner (split system) includes:
Conditionerunitforindoorinstallation -1 piece
Conditionerunitforoutdoorinstallation-1 piece
Remote control-1 piece
Batteries for remote control board - 2 pcs.
Operator's manual-1 piece
Warranty card-1 piece
Packing of indoor-installation unit-1 piece
Packing of outdoor-installation unit-1 piece
6. DEVICE CONTROL
The conditioner is controlled from a remote control board or from a control
panel of the indoor unit.
Figure 2. Description of indoor unit control board
U'ml', • U
<
Z
0
HMft
c
Bl
Vi
0
O
o
10
11
12
13
14
15
1. Conditioner unitfor indoor installation
2. Control and indication panel 10 .
3. Blinds (deflectors) for distribution of treated air 11 .
4. Air inlet of indoor unit 12 .
S.Tube for condensate removal 13 .
6.Coppertubeforgas(freon). 14 .
7. Conditioner unitfor outdoor installation 15 .
8. Air inlets of outdoor unit
9. Return air grillages of outdoor unit
Control and indication board ofyour conditioner may visually differ from a
layoutviewshown below. Its functions will remain the same.
