Part 9:
Gas convertion
Your cooker can operate both Natural
Gas and LPG. You can convert by
changing the gas source and the top
burner, oven and grill injectors. The
replacement procedure of the injectors
are explained below.
Call authorized Service for gas
convertion.
Replacement of the top burner
injector
Take off the burner head and burner
cap before starting this procedure.
Then:
1. Remove the injector inside the top
burner with a suitable bit. Later, install
the new injector by covering the injector
threads
with leakage
preventing
material.
Reduced Tap Flow
1. Ignite the burner that should be adjusted, turn
the knob to the reduced position, pull and take
the knob off.
2. With a screwdriver, make the tap reduced flow
adjustment from the injector that is on the gas
tap (only the head is visible with the bolt shape).
It is sufficient to tight to screw
completely, in butane/propane gas.
For the natural gas, you should turn the screw
counter-clockwise
once. The normal length of a straight flame in
the reduced position
should be 6 - 7mm.
If the flame is higher than the desired position,
turn the screw clockwise. If its smaller to the
opposite.
For the last control of the burning of the cooker,
bring the cooker high-flame and reduced positions
and check whether the flame is on or off.
31
