Recording
Reducing noise when recording AM
Remote control only
Hold down [PLAY MODE] while recording.
Every time you hold down the button: BP1 ^ BP2
Choose the setting with the least noise.
идя
• Changes to volume and sound/field quality do not affect recording.
• You cannot open deck 1 while recording.
• You cannot fast-forward or rewind one deck while recording with
the other.
• When recording an AM broadcast, sound is momentarily interrupted
when you start and stop the recording.
Side A -
Erasure prevention
Use a screwdriver or similar
object to break out the tab.
Tab for side B
To re-record on a protected cassette
Cover the hole with adhesive tape.
To erase a tape
1. Press [►, TAPE] and then [■, STOP].
2. Insert the recorded tape into deck 2.
Ensure there is no tape in deck 1.
3. Press [• REC],
Tab for side A
Optional antenna connections
• Disconnect the FM indoor antenna.
• The antenna should be installed by a competent technician.
AM outdoor antenna
For Europe AM outdoor antenna (not included)
For Australia and
New Zealand
RQT6699
Run a piece of vinyl wire horizontally across a window or other
convenient location.
Leave the loop antenna connected.
Disconnect the outdoor antenna when the unit is not in use.
Do not use the outdoor antenna during a lightning storm.
External unit connections
Analogue equipment
An analog player with a built-in phono equalizer can be connected.
Analog player
(not included)
Digital equipment
(Only for areas excepf Russia, Ukraine, Australia and New Zealand)
A digital equipment with an optical fiber terminal can be connected.
Optical fibre cable
• For details, refer to the instruction manual of the units which are to
be connected.
• When units other than those described above are to be connected,
please consult your audio dealer.
Using an external unit
• REC-
AUX
(See above for external unit connection.)
1. Press [AUX].
The unit comes on.
2. For listening: Proceed to step 3.
For recording; Press [• REC] (recording starts).
3. Start playback from the external source. (For details, refer fo the
external unit's instruction manual.)
Using headphones (not included)
•
*=11 1
HI-
Headphones
(not included)
Reduce the volume level and connect the headphones.
Plug type: 3.5 mm stereo
Avoid listening for prolonged periods of time to prevent hearing damage.
