(-♦16, 18)
3 f^±;t®lf^OPEN|ffi,
i^90" o
• '£';PJi;f«nuiLfw!i£giEiS}4y±5£iii iltt, 'g'll
fim-si-mimm. liT'giivaaus.isasfajL
4
;f»)Mi)^th[EJECTA
J
m&o
6
i^iJi^iilLOCKliiOo
ttitfiPWgv, ;tKlS/S»ib|EJECTd^ Iffi©, m&-$:d\tm
JglLOCKlillO, SI-tiiimiTsit.,
Inserting the Cassette
1
Connect the AC Adaptor or attach a
charged Battery. (-> 16, 18)
2
Turn the cog wheel O to tighten the
tape.
3
Slide the
[►
OPEN] Lever upward and
simultaneously open the LCD Monitor
in the direction of the arrow
approximately 90°.
• Be sure to keep the LCD Monitor in its vertical
position, so that the Cassette Compartment Cover,
when it opens, does not hit the LCD Monitor.
4
Slide the Cassette Eject [EJECT A]
Lever @ in the direction of the arrow.
5
Insert the cassette with the cassette
window O facing outwards and push
it all the way in.
6
Close the Cassette Compartment by
pressing the [LOCK] Button ©.
■ Ejecting the Cassette
Slide the Cassette Eject [EJECTA] Lever 0 in the
direction of the arrow and pull out the cassette.
Close the Cassette Compartment by pressing the
[LOCK] Button O-
24
