English
3
Partsidentification



 




 



a
b



ER-GC70 ER-GC50

A Main body
1 Dial
a. Scale marks
b. Instruction marks
2 Charge indicator lamp
3 Power switch [0/1]
B Blade block
4 Cleaning lever
5 Moving blade
6 Stationary blade
7 Mounting hook
C Comb attachment [A]
(1 mm to 5 mm)
D Comb attachment [B]
(6 mm to 5 mm)
E Comb attachment [C]
(6 mm to 45 mm)
F AC adaptor (RE9‑49)
8 Power cord
9 Appliance plug
G Oil
H Cleaning brush
I Travel pouch
Accessories ER‑GC70 ER‑GC50
C Comb attachment [A] (1 mm to 5 mm)
D Comb attachment [B] (6 mm to 5 mm)
E Comb attachment [C] (6 mm to 45 mm) ‑
I Travel pouch ‑
Chargingtheclipper
You can fully charge the clipper in 8 hours if it is losing speed.
A full charge supplies enough power for approximately 40 minutes
of use.
1.Slidethepowerswitchonthemain
bodytothe“0”positiontoturnoff
theclipper.
2.PlugintheACadaptorintoa
householdoutlet.
3.Inserttheapplianceplugintothe
clipper.
The charge indicator lamp lights and
stays on until the AC adaptor is removed
from a household outlet.
4.DisconnecttheACadaptorfroman
outletwhenchargingiscompleted.
2
3
1
When charging the clipper for the first time or when it has not been
in use for more than 6 months, please charge it for 16 hours (in
order to activate the rechargeable battery). If you charge the
clipper with the battery completely discharged, the charge
indicator lamp may not glow immediately. However, the lamp will
glow normally after charging for a few minutes.
