ENGLISH
22 ASSEMBLING AND PREPARING
Adjusting the angle of the TV to suit view
(This feature is not available for all models.)
Swivel 15 degrees to the left or right and
adjust the angle of the TV to suit your view.
(Only LA79**)
15 15
Swivel 10 degrees to the left or right and
adjust the angle of the TV to suit your view.
(Only 42/47LA860*)
10 10
Swivel 8 degrees to the left or right and
adjust the angle of the TV to suit your view.
(Only 55/60LA860*)
8 8
CAUTION
y When adjusting the angle adof the
product, watch out for your fingers.
» Personal injury may occur if hands or
fingers are pinched. If the product is
tilted too much, it may fall, causing
damage or injury.
<Rear> <Front>
Securing the TV to a wall
(This feature is not available for all models.)
1 Insert and tighten the eye-bolts, or TV
brackets and bolts on the back of the TV.
- If there are bolts inserted at the
eye-bolts position, remove the bolts
first.
2 Mount the wall brackets with the bolts to
the wall.
Match the location of the wall bracket
and the eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets
tightly with a sturdy rope.
Make sure to keep the rope horizontal
with the flat surface.
