ViTESSE VS-657 - Инструкция (Страница 4)

P/5 P/6
www.vitesse.ru
Turbo Steam Ironing
Vertical steam ironing:
Auto-shut off function
Turbo Steam feature provides additional steam for removing stubborn creases.
1. Set the "adjustable steam knob" to " 0 "position(Fig.2), and then fill the water
tank with clean tap water refer to above filling instruction.
2. Connect the appliance to a suitable main socket, set the temperature control
button to "MAX" position. The power indicator light will blink, which indicate
that the unit being heated up, When the power indicator light change to light up
steadily, the required temperature has been reached.
3. Press the turbo steam button two or three times in quick succession to obtain
more powerful turbo steam.
4. It is normal that a small amount of water may be ejected from the soleplate
when pressing turbo steam button so frequently that temperature of soleplate
will be decreased accordingly. It is supposed to stop pressing turbo steam
button, and allow it to heat up again.
5. After use, turn adjustable steam knob to “0”position, disconnect the appliance
from power socket.
6. Before storing, please allow the unit completely cool down. Caution: when
using turbo steam ironing, turn adjustable steam knob to ”0” position.
Vertical steam ironing is especially used for removing creases from hanging
clothes and curtains
1. Set the adjustable steam knob to “0”position,fill water
into water tank as described in water filling instruction.
2. Connect the appliance to suitable power socket, and
then set temperature control button to the max
temperature setting. The power indicator light will
blink, which indicate that the unit being heated up,
When the power indicator light change to light up
steadily, the required temperature has been reached.
It is ready for vertical steam ironing.
3. Hold the iron in vertical position as shown in Fig.7, and then press down the
steam button, vertical steam will go out from the steam outlet of the soleplate.
Never perform steam ironing directly on person.
VS-657:
The appliance will automatically shut off if it has been successively used for about
60 minutes, and all indicator light will go out. To continue ironing, only press the
temperature control button again.
VS-657-M:
When the iron is stationary in horizontal position for about 30seconds or in vertical
position for about 8 minutes, the unit will auto-shut off. All indicator lights turn off.
Press down the reset button or allow the
iron move from front to back.. it will be reacted to original fabric setting again.
Anti-drip system:
Anti-calc system:
Maintenance:
This appliance has a safety mechanical protection which can protect water drip
from the soleplate when the temperature of steam chamber decrease so low that
it cannot provide steam, therefore it is normal that the steam go out of the steam
outlet un-continuously during use.
1. The anti-calc box as shown in Fig. 8 is designed to purify hard
water and reduce the build-up of limescale which occurs during
steam ironing, this will prolong the working life of your iron.
2. The anti-calc box should be replaced with a new one after two
months, in case of using one time each day, and you can
contact with manufacturer or agency for purchasing a new one.
3. To replace the anti-calc box, take it out of the water filling hole,
and then replace with a new one.
After several use of your iron, a little amount of limescale will be built up in the
steam chamber and steam outlet, following up below selfcleaning process, it will
be well removed.
1. Set the adjustable steam knob to" 0 "position.
2. Fill water tank with water to max filling line.
3. Place the iron on the ironing rest, and put a
sink under the ironing rest to prepare for
pouring water and ejecting steam.
4. Set temperature control button to "MAX"
position.
5. Plug the unit into the main socket.
6. Allow the iron to heat up for 2 minutes
7. Disconnect the iron from main socket.
8. Hold the iron horizontally over the sink.
9. Press the self-cleaning button. (Fig.9)
10. Boiling water and steam will emit from the outlet of the soleplate and wash
away the impurities and scale.
11. Move the iron backwards and forwards while this happens. Go on letting
steam and water escape until the water tank is virtually empty.
12. Set the adjustable steam knob to “0” position.
13. Insert the iron into main socket again.
14. Set the temperature control button to “MAX” position, Let the iron heat up
again. The remainder of the water inside the steam chamber will now
vaporize.
15. Unplug from power supply and allow soleplate to cool down and wipe it clean
with a soft damp cloth.
Fig.7
Fig.8
Fig.9
