Fill Water Tank
Make sure that the iron is unplugged from main socket
before filling water into the water tank.
1. Set the adjustable steam knob to " 0 " position (Fig.2)
2. Take Anti-calc box out of the filling hole (Fig.3)
3. Using a cup, slowly pour tap water or distilled water
into the water tank as shown in Fig.4 .
Never to fill beyond the Max filling line.
4. Replace the Anti-calc box into the filling hole as shown in Fig.5 .
5. Hold the iron in horizontal direction, and then move the iron front and back for
about 30 seconds so that limescales in water can be purified by the ion
exchange resin in the Anti-calc box.
P/3 P/4
www.vitesse.ru
fig.3 fig.4 fig.5
fig.2
Steam ironing
Note:
VS-657
VS-657-M:
Dry Ironing
Note:
1. Place the iron on a level, horizontal ironing board
2. Set the adjustable steam knob to " 0 " position(Fig.2), and then fill the water
tank with clean tap water refer to above filling instruction.
3. Connect the appliance to a suitable power socket, set the temperature control
button to "MAX" position. The power indicator light will blink, which indicate
that the unit is being heated up, When the power indicator light change to
illuminate, the required temperature has been reached. In this stage, it is
normal that a "pong" sound produced, it because that the steam switch
automatically turn on.
4. For every first use, press down the turbo steam button several times
continuously, and then press down the self-cleaning button for about 10
seconds to clean the steam chamber.
5. Set temperature control button to desired position
according to different fabrics, put the adjustable steam
knob to " " position (Fig.6), and then steam will come
out from steam vents of soleplate. During steaming
iron, it is normal that the power indicator light cycle from
blinking to illuminate steadily. It is because the
appliance automatically heat preservation.
6. After use, turn adjustable steam knob to " 0 "position,
disconnect the appliance from power socket.
7. Before storing, allow the unit completely cool down.
1. For every first use,the appliance should be pre-heated for about 2 minutes.
2. During steam ironing, it is normal that steam is stopped for a while, which may
be caused by lower temperature of soleplate or steam rate is so high that the
anti-drip system automatically reacted.
3. When setting the temperature control dial on ” ” position, there are
no steam go out of the soleplate since the temperature of soleplate is so low
that it can not produce steam.
Allow the iron resting motionlessly on the soleplate or on its heel, the
unit will come into auto-shut off mode, please refer to the auto-shut off
function described below.
1. Place the iron on a level, horizontal ironing board
2. Set the adjustable steam knob to “0”position(Fig.2).
3. Connect the appliance to suitable power socket, and then set temperature
control button to the desired position according to different fabrics. The power
indicator light will blink, which indicate that the unit being heated up, When the
power indicator light change to steadily illuminate, the required temperature
has been reached. It is ready for dry ironing.
4. If water spray is necessary, press down the spray button two or three times in
quick succession, water can be sprayed evenly in the fabric.
5. After use, disconnect the appliance from main socket.
6. Before storing, allow the unit completely cool down.
When changing your temperature control button from high setting to
lower, it is proposed that not to start ironing immediately since there may be
any burns caused on your fabrics by high temperature. Please wait for the
indicator light illuminate steadily, and then start ironing.
FABRIC SETTING CHART
1 (Low) 2 (Medium) 3 (High) (Max)
Shut
off
Rayon
Cotton,
Linen Rayon
Cotton,
Linen
Steam
ironing
Iron while
fabric is still
damp using
steam and
spray
Use a press
cloth and
steam or dry
ironing on the
opposite side
of the fabric
Wool, Silk
Polyester
Temperature
Setting
Fabric
Iron
Instructions
Dry Ironing
on the
opposite
side of the
fabric
Synthetics,
Nylon,
Acetate
Note: When using distilled water, you can mix it with tap water in a
proportion of 50%.
fig.6
/
