1. Pusher
2. Tray
3. “T” Piece
4. Fixity keystoke
5. Tool box cover
6. Moment switch-knob (REV)
7. Revolve Switch-knob (I/O/II)
8. Body
9. Screw pusher
10. Big hole knife 11. Small hole knife
12. Revolve knife
13. Middle hole knife
14. Fixation nut
15. Long sheath
16. Short sheath
17. Plastic sheath 01
18. Plastic sheath 02
P/1 P/2
HOW TO USE
Mincing
See below figure 2
1. Insert the worm shaft into the cutter housing, the platic end first. Fit the cutter
blade unit onto the other end of worm shaft. (The cutting edge should be
placed at the front side). And then you can also fit the coarse/medium/fine
grinding disc (Depending on the consistency you prefer). Make sure the notch
of the grinding disc fit into the projection on the opening of cutter house. Fit the
screw ring on the cutter housing by turning the screw ring clockwise until it is
properly fastened.
2. Fit the cutter housing on the motor unit. The lugs on the motor unit must fit
precisely into the slots on the cutter housing. Rotate the cutter housing anti-
clockwise until hear a click. The cutter housing is then locked in the position
You can remove the cutter housing by pressing the release button on the
appliance and turning the cutter housing clockwise.
3. Place the tray on the upright part of the cutter housing.
4. Now the appliance is ready for mincing.
MINCING:
Cut the meat into 10 cm long, 2 cm thick strips. Remove bones, pieces of gristle
and sinews as much as possible.
Note: never use frozen meat!
Place the meat on the tray. Use the pusher to gently push the meat into the cutter
housing.
For steak tartare, mince the meat with the medium grinding disc twice.
www.vitessehome.com
Dear Customer!
You have made an excellent decision. Vitesse® “Nouveau” home range offers
you an exclusive, high quality range of appliances for your ultimate home
luxury and healthy living.
BEFORE USING
Read these instructions thoroughly first and keep them for future reference.
Check whether the voltage in the home corresponds with that of the appliance.
Only connect this appliance to an earthed electric socket.
Remove all packaging materials and stickers from the appliance. Clean the
appliance and all removable accessories and dry them thoroughly (see
”Cleaning and maintenance”). Place the motor unit on a flat and stable
surface.
Structure Illustration
